Powering the Next Generation of Semiconductor Innovation

Film — THE ALE BY AATWatch ▶
// Where conventional RIE hits its limit
Conventional RIEAI-native ALE
01Sub-3nm logic nodes
02300+ layer NAND stacks
03Vertical DRAM architectures
04Silicon photonics supply chain
AI-native ALE is the way through
// The inflection

The manufacturing inflection is here.

Are your process and products keeping up?

AI-driven semiconductor process visualization
Fig. — AI-native process controlAI

At sub-3nm logic nodes, inside increasing 3D NAND stacks, across the transition to vertical DRAM architectures, and throughout the growing silicon photonics market, conventional reactive ion etch is hitting its limits.

The common thread is not the device type. It is the precision requirement. At each of these inflection points, the etch step that determines yield is one that demands atomic-scale control — and ALE adoption is accelerating, with intensity expected to grow 20X over the next several years.

// Proven

Proven performance.

AAT's platform has been independently validated at SPIE Advanced Lithography + Patterning, demonstrating true self-limiting ALE behavior across two operating modes:

High Throughput Mode
~0 Å/ cycle
Etch per cycle (EPC)
  • Synergy Factor>90%
  • Linearity (R²)>0.9997
  • Cycle Time~2 seconds
High Precision Mode
~0 Å/ cycle
Etch per cycle (EPC)
  • Synergy Factor>80%
  • Linearity (R²)>0.9947
  • Cycle Time~2 seconds
// Get in touch

Deep expertise. Startup speed. Real results

Talk to our team about process development, equipment demonstration, or partnership opportunities.
